Customization: Available
Type: Li-ion Battery
Cathode Material: LFP
Send Inquiry

Product Description

Basic Information
Model NO.
ELT15K100H
Rechargeable
Yes
Voltage
Hv 153.6V-512V
Capacity
100ah
Energy Range
10kwh - 60kwh
Warranty
5 Years
Cycle Life
6000 Times
Certification
CE/RoHS/Un38.3/MSDS
High Voltage Stackable ESS Solutions
High Voltage Stackable ESS
🛡️ Safe and reliable LiFePO4 battery cells
📈 Flexible investment for energy requirements
⚡ Highest energy efficiency performance
🔌 Wide compatibility with main inverters
Technical Specifications
Typical Model ELT15K100H ELT20K100H ELT25K100H ELT30K100H ELT40K100H
Battery Modules 3 4 5 6 8
Nominal Energy 15.36kWh 20.48kWh 25.6kWh 30.72kWh 40.96kWh
Nominal Voltage 153.6V 204.8V 256V 307.2V 409.6V
Max Current 100A (Continuous) / 150A (Peak 10s)
Communication CAN / RS485
Dimensions (mm) 550*470*712 550*470*885 550*470*1058 550*470*1231 550*470*1577
Weight (kg) 177 227 277 327 427
Product Gallery
Module View 1 Module View 2 Module View 3
Interface Detail System Setup 1 System Setup 2
Advanced Protection & Compatibility
Protections
Over/Under Voltage, Over Current, Temperature, DC Breaker
Inverters
Deye, Sofar, Growatt, Goodwe, Megarevo, Afore
IP Rating
IP65 (Indoor/Outdoor capable)
Cooling
Natural Convection
Battery Advantages Certifications Display
Packaging & Logistics

Batteries are packed with high-quality pearl wool, UN cartons, or plywood cases on plastic pallets for maximum safety during transit.

Shipping and Packaging
Frequently Asked Questions
1. What is the minimum order quantity (MOQ)? Sample orders for testing are fully supported. You can order as little as one piece to evaluate quality and performance.
2. What is the standard warranty for the ESS? The standard warranty term is 5 years. Extended warranty options are also available based on specific project requirements.
3. Can I expand the capacity later? Yes, the stackable design allows for flexible expansion. You can start with 3 modules and expand up to 8 modules per stack (40.96kWh) as your energy needs grow.
4. Which inverter brands are compatible with this battery? Our system is widely compatible with major market brands including Deye, Growatt, Sofar, Goodwe, Megarevo, and Afore via CAN/RS485 communication.
5. What is the typical lead time for orders? Sample orders usually take 15-20 days. For bulk orders, the lead time is approximately 25-30 days depending on the quantity and customization requirements.
6. How are the batteries shipped? We offer multiple shipping methods including sea freight (25-45 days), railway (15-35 days), and express/air for urgent samples (3-15 days).
