Longer Cycle Life
Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery, minimizing replacement cost.
Lighter Weight
About 40% of the weight of a comparable lead acid battery. A "drop in" replacement for lead acid batteries.
Higher Power
Delivers twice the power of a lead acid battery, even at high discharge rates, while maintaining high energy capacity.
Wider Temperature Range
Operational range from -20ºC to 60ºC.
Superior Safety
Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact or overcharging.
Applications:
♦ Wheelchairs and scooters ♦ Solar/wind energy storage ♦ Back-up power for small UPS ♦ Golf trolleys & buggies ♦ Electric bikes
| Category |
Parameters |
| Nominal Parameters |
Voltage |
48V |
| Capacity |
200Ah |
| Energy |
9.6kWh |
| Dimensions(L x W x H) |
680x480x180 mm |
| Weight |
96.5kg |
| Basic Parameters |
Life time(25ºC) |
20 years |
| Life cycles(80% DOD) |
6000 Cycles |
| Operation temperature |
-20°C to 60°C |
| Storage temperature |
0°C to 45°C |
| Lithium Battery Standard |
UL1642, IEC62619, UN38.3, MSDS, CE-EMC |
| Protection Rating |
IP21 |
| Electrical Parameter |
Max. charging voltage |
54 VDC |
| Cut-off Discharge Voltage |
42 VDC |
| Max. current |
120A (5760W) |
Frequently Asked Questions
1. What is the expected cycle life of this LiFePO4 battery?
This battery pack offers up to 6000 cycles at 80% Depth of Discharge (DOD) at 25°C, providing a long-term reliable energy solution.
2. How does the weight compare to traditional lead-acid batteries?
The LiFePO4 battery is approximately 40% of the weight of a comparable lead-acid battery, making it much easier to handle and install.
3. What safety features are integrated into the battery?
It features a Smart BMS and Lithium Iron Phosphate chemistry which eliminates the risk of explosion or combustion due to high impact, overcharging, or short circuits.
4. Can this battery be used in extreme temperatures?
Yes, the operation temperature range is wide, from -20°C to 60°C, suitable for various environmental conditions.
5. What certifications does this product hold?
The battery meets several international standards including UL1642 (Cell), IEC62619, UN38.3, MSDS, and CE-EMC.
6. What are the primary applications for this 48V 200Ah system?
It is ideal for solar and wind energy storage, backup power for UPS systems, electric wheelchairs, scooters, and golf trolleys.
